8860 7-Inch Touchscreen Keypad
8860 7-Inch Touchscreen Keypad

8860 7-Inch Touchscreen Keypad

8860 Keypad Layout.png

The 8860 7-Inch Touchscreen Keypad provides a full-color, capacitive touchscreen interface for managing DMP security systems. Its touchscreen design provides intuitive access to system functions, menus, video features, and connected devices. The keypad includes an on-board 2MP camera, internal speaker, and support for optional panic keys.

The 8860 can communicate with compatible DMP panels through Wi-Fi or the keypad bus, allowing it to be installed in a variety of system configurations. When connected to a network, the keypad provides access to additional video and system-management features.

Features

  • 7-inch touchscreen — Provides a large, full-color, multi-touch display for navigating the security system.

  • Built-in audio — Includes an internal speaker for zone annunciation and 2-way audio to cameras and video doorbells.

  • Flexible installation options — Can communicate with compatible panels using Wi-Fi or the keypad bus.

  • Interactive arming and disarming — Provides an intuitive interface for arming and disarming the system and selecting areas or system configurations.

  • Video integration — When network-connected, the 8860 can display live video and video clips from compatible DMP video devices, including VUE video doorbells and cameras.

  • Arming/Disarming snapshots — The onboard 2-megapixel camera can capture verification snapshots associated with arming and disarming events.

  • Bluetooth disarming — Allows authorized Bluetooth devices to be used for convenient system disarming. Current 8860 firmware supports up to six Bluetooth disarming devices.

  • Z-Wave control — Provides enhanced control of supported Z-Wave devices from the keypad.

  • Carousel Menu — Provides quick access to frequently used features and connected devices.

  • System status and events — Displays system status, attention events, and other information to help users monitor the security system.

  • Remote updates — Network-connected keypads can receive updates remotely through Dealer Admin, helping keep the keypad current without requiring an installer to update each device locally.
